D06M-DF4 Series

Medical DIP 85%~89% 9-36 VDC, 18-75 VDC 1V~5V, 5V~10V, 12V~20V Isolated DC-DC converter 1W~29W

Technische Eigenschaften

Medical Isolated DC-DC converter
4:1 Wide input range voltage
6W power in standard DIP 24 package
Clearance and creepage distance @ 250Vac working voltage
4000Vac isolation for 2MOPP application
Efficiency up to 88%
Built-in EMI class A filter
Continuous short circuit protection
UL94V-0 package material
Medical safety meets 2xMOPP per 3rd Edition of IEC/EN 60601-1

Wird verwendet für

The series of DC-DC medical converter in industrial standard pin-out DIP24 package, are capable of delivering 6 watts. They are designed for high end industrial application, medical application.
